Explosive atmospheres – Part 33: Equipment protection by special protection ‘s’

Explosive atmospheres – Part 33: Equipment protection by special protection ‘s’

IEC 60079-33 ‘s  self-introduction is as follows:-

The purpose of IEC 6 0079-33 special protection “s” for any equipment protection level (EPL) is to allow design, assessment and testing of equipment or parts of equipment that cannot be fully assessed within a recognized type of protection or combination of recognized types of protection because of functional or operational limitations and where the desired equipment protection level can be achieved by the use of this standard.

This standard is intended to provide a framework to demonstrate how essential safety requirements can be met if not covered by established standards, thus allowing for innovation and dealing with unknowns.



The creation of IEC 60079-33 is linked directly to the History of IEC Ex , when sometimes around or a bit before  2012, a  request from the IECEx certification system was submitted to IEC to creat a road-map for certification (within the IECEx product certification Scheme) for such cases where the  standards for existing types of protection were not applicable.

History of IEC Ex

(Source IEC e-learning )

More interesting facts  on History of IEC 60079-33 by Ron Sinclair http://www.hazardexonthenet.net/article/23777/How-Special-is-Special-Protection-.aspx

 The need for a standard to address special protection “s” can be justified on the basis that:
• provision has been in IEC 60079-0 for many years with reference Ex “s” in a note in the
marking requirements or elsewhere. This reference goes back to IEC standards that predate
• there have been standards used on a national basis for many years for certification to
special protection “s”. Examples are SFA 3009 in the UK and AS/NZS 1826 in Australia
and New Zealand;
• it is necessary to have an international approach that is consistent;
• there is an identified need and has been a request for a special protection “s” standard
from IECEx.



Let us bring IEC 60079-33 into the spotlight

IEC60079-33 Spotlight

The scope of IEC 60079-33 lies beyond the present protection techniques as stated in IEC 60079 series


IEC 60079-33 is to be consulted only when all the existing options have been exhausted and the Ex Designers  have to step into new a dimension , with a broad perspective.


Crossing-over and going beyond the safety steps of IEC 60079


..into the innovative land-of-options of IEC 60079-33


….and explore the protocol of this domain.


The most important part of the protocol is the INDEPENDENT VERIFIER

Independent verifier
A Person or organization, with the appropriate competency in the applied explosion protection methodology, responsible for the verification of design calculations, assessment and testing who are separate and distinct by management and other resources including financial, from the person or organizations responsible for all the activities associated with the design, manufacture or sales of the equipment.     (IEC 60079-33 )

Of course, the need for the application of Special Safety “s” is initiated by the manufacturer along with the road-map/details of the process to verify the required level of safety .

The involved , level of Ex Competency of all the stakeholders ,clearly shows that IEC 60079-33 is only for the Ex-PERTS

IEC60079-33 Landscape


IEC 60079-33 is quite sensitive about the role, and in turn the specifications of the Independent Varifiers .

Section 5 (IEC 60079-33 Edition 1, 2012) gives us the details about the :-

1. State of being Independent .

This the most important aspect of  an Independent Varifier so that the final endorsement procedure is not biased or tinted.

Independent verifiers shall be independent from the applicant and any organization that is involved in the design, manufacture or sale of the equipment. They shall be separate and distinct from those organizations by management and financial or other resources, so that any influence or pressure on the decision-making process, the assessment and the results can be excluded.(IEC 60079-33)

In section 6 ,there is reference to The Principles of Integrated Approach to Explosion Safety ,so let us remind ourselves, while designing an electrical equipment intended for use in explosive atmosphere,  the application of the following golden principles :

(The 3 levels approach)

1. The electrical equipment should not release or produce explosive atmosphere at any level .

2. If explosive atmosphere do exists then ignition is to be prevented at all levels , taking into account, all the electrical-ignition sources.

3. The Aftermath of an explosion. An extensive analysis should be carried out so as to ensure the safety of persons & property at stake.

The road-map emerging from the application of these three principles will direct us to the EQUIPMENT PROTECTION LEVELS (EPL)
