Flameproof

The Name of the Safety Technique : Flameproof

Symbol :  d


IEC Document : IEC60079-1

Parts which can ignite a potentially explosive atmosphere are surrounded by an enclosure which withstands the pressure of an explosive mixture exploding inside the enclosure and prevents the transmission of the explosion to the atmosphere surrounding the enclosure.

Type of Ignition Protection Abbreviation Region Classification  Specification/Standard
Flameproof Enclosure AEx d US Class I, Zone 1 ISA 60079-1
Flameproof Enclosure Ex d CA Class I, Zone 1 CSA E60079-1
Flameproof Enclosure Ex d (EEx d) EU Zone 1 EN 60079-1
Flameproof Enclosure Ex d IEC Zone 1 IEC 60079-1
Explosion Proof XP) US Class I, Division 1 FM 3615
(XP) CA Class I, Division 1 C22.2 No. 30

The Level of Protection & corresponding Equipment Protection Level associated with Flameproof Enclosures  (d) are as follows:

Level of Protection da  (EPL ‘Ma’ or ‘Ga’)

Level of Protection db  (EPL ‘Mb’ or ‘Gb’)

Level of Protection dc (EPL ‘Gc‘)

Application

1. Machine Control Syatems

2. Power Distribution Systems

3. Terminal Boxes

4. Motors

5. Switch Gear

6. Motor Switches

7. All Power distribution & control applications,  involving non-certified industrial components


Background

This is one of the oldest Explosion protection Techniques , still in use today. The basic philosophy is SEGREGATION or separation of the Explosion Causing Elements  from the Explosive Atmosphere by providing a strong metallic enclosure for the Electrical Components and sealing it properly so that the the  spark-producing electrical component is COMPLETELY separated from the Explosive Atmosphere .

IF however , the explosion does take place inside the enclosure then the residual material (Smoke or flames) remains inside the enclosure because of the strength of the enclosure-material and the extra pressure is released through the special joints of the enclosure-lid so that the escaping smoke and flames are cooled sufficiently. These special joints are called “Flame Paths “.

(See post : Maximum Experimental Safe Gap)

The basic component which provide the protection in the hazardous area (GAS or Dust) is thus the ENCLOSURE.

  • Therefor it has to be strong (Logically ; metallic),
  • carefully designed
  • and evaluated  with the electrical components  installed inside, for the different component-failure scenarios .

CAUTION :

Buying a certified EMPTY ENCLOSURE (Ex d) , with a ‘U’ certificate and populating it with industrial type electrical components ,in your own workshop, to sell it as a Certified Ex d Assembly is both DANGEROUS and Prohibited.


expeltec ex d box



More about Ex d Enclosures .
